Solar Monoblock Pump

Water output figures are on a clear sunny day with 3 times tracking of SPV panel, under “Average Daily Solar Radiation” condition of 7.15 KWh/sq.m on the surface of PV Array (i.e. coplanar with PV module) 2 Standard Test Condition : AM=1.5, E=1000W/m , Cell Temperature : 25°C

Tsquare Green Energy offers solar surface monoblock pumps ranging from 1 HP to 5 HP. These pumps are easy to install, have low maintenance cost and offers greater efficiency. Due to its compact size and superior build quality, Tsquare Green Energy surface monoblock pumps can be used in agricultural, industrial and commercial sectors with ease.

Hp/Kw	Stage	Voltage	Mechanical Watt	Discharge Outlet (Inch)	Suction Outlet (Inch)	Head (In Meters)	Discharge In Lpm	Shut Off Head	Overall Efficiency	Maximum Amp	Size Of Cable	RPM
1 Hp / 0.75 Kw	1	160 V	800 W	2 "	2 "	10 Meter	300 Lpm	18 Meter	30.00%	3.5 A	1 * 3 * 2.5 Sq.Mm	2800
1 Hp / 0.75 Kw	1	160 V	800 W	3 "	3 "	6 Meter	600 Lpm	12 Meter	30.00%	3.5 A	1 * 3 * 2.5 Sq.Mm	2800
2 Hp / 1.5 Kw	1	350 V	1600 W	2 "	2.5 "	12 Meter	450 Lpm	24 Meter	30.00%	4.0 A	1 * 3 * 2.5 Sq.Mm	2800
2 Hp / 1.5 Kw	1	350 V	1600 W	3 "	3 "	8 Meter	700 Lpm	18 Meter	30.00%	4.0 A	1 * 3 * 1.5 Sq.Mm	2800
3 Hp / 2.2 Kw	1	230 V	2400 W	3 "	3 "	8 Meter	900 Lpm	22 Meter	30.00%	8.0 A	1 * 3 * 4.0 Sq.Mm	2800
3 Hp / 2.2 Kw	1	230 V	2400 W	4 "	4 "	8 Meter	1200 Lpm	14 Meter	30.00%	8.0 A	1 * 3 * 4.0 Sq.Mm	2800
5 Hp / 3.7 Kw	1	380 V	4000 W	3 "	3 "	6 Meter	1200 Lpm	26 Meter	40.00%	8.0 A	1 * 3 * 6.0 Sq.Mm	2800
5 Hp / 3.7 Kw	1	380 V	4000 W	4 "	4 "	6 Meter	1600 Lpm	18 Meter	40.00%	8.0 A	1 * 3 * 6.0 Sq.Mm	2800
